1. Install the cutter headAlign the cutter head and place it into the container
2. Assemble the discharge baffle and guide plate (align the two holes during installation)
3. Place the storage cover on the storage bowl, ensuring that the positioning of the storage cover aligns with the guide plate cylinder
4. Place the host on the storage cover (the host and the storage cover must be in close contat)
5. Press the “jog” button to peel the skin
6. After peeling, press the “discharge” button

Product components

1. Host 2. Storage cover 3. Guide plate 4. Knife disc 5. Storage bowl 6. Discharge stopper

Product installation

1. Assemble the discharge baffle and cutterhead
2. Assemble the guide plate, paying attention to aligning the two holes on the guide plate with the two protruding ribs on the edge of the storage bowl during installation
3. Cover the storage cover on the storage bowl, paying attention to aligning the positioning of the storage cover with the cylinder on the guide plate
4. Place the host on the storage cover, making sure that the host and storage cover are glued together Usage

1. Prepare fruits: Choose round or oval fruits (<150g), wash them dean and free of foreign matter, and drain as much water as possible.
2. Placing fruits: There are two ways to place fruits

1. Take off the host and place the fruit on the blade of the storage bowl of the peeler. Then place the host on the storage cover.
2. Ensure that the machine is not operating, open the storage lid, pour in the fruit, cover the lid, and then place the main unit on top of

the fruit and vegetable peeler stable and strictly prohibit the knife disc from reaching into it while rotating.

1. Start the machine: Press the jog switch function key to start the fruit and vegetable peeler. During the peeling process, please keep
2. After peeling, press the discharge button and the fruit will automatically come out of the discharge port. The knife assembly will stop

running, and the peeling is complete!

prevent the fruit peel from sticking to the product parts after drying and not being cleaned

5. Cleaning and maintenance: After completing all fruit peeling functions, please clean the corresponding parts in a timely manner to Charging mode:

a. After connecting the adapter, the LED light flashes green

b. After being fully charged, the LED light displays a constant green light. Cleaning method for fruit and vegetable peeler Before cleaning

1. please confirm that the blade has stopped running to prevent scratches.
2. Do not use steel wire balls, abrasive cleaners, or corrosive liquids to clean this product.

3. The host can be wiped with a wrung out damp cloth. Do not clean, soak or spray it in water or other liquids to avoid device damage

or product leakage

4 Please rinse the inside of the storage bowl and the parts in contact with food with clean water, and promptly dry or air dry them.

Please handle with care to avoid scratching or cutting your hands (it is recommended to wear protective gloves for cleaning)

5. When storing and organizing, please ensure that the products are clean, dry, and placed in a dry, ventilated area, away from direct

sunlight
